SIF54S30 MR P-Type Single-Glass PV Module

  • SIF54S30 MR P-Type Single-Glass PV Module
  • SIF54S30 MR P-Type Single-Glass PV Module
Wenzhou Sairifu New Energy Technology Co., Ltd.

SIF54S30 MR P-Type Single-Glass PV Module

PREV：SIF72S30 LR P-Type Single-Glass PV Module NEXT：No next article
  • Product Details
  • FAQ
  • Contact Us
Model SIF54S30 400/MR SIF54S30 405/MR SIF54S30 410/MR SIF54S30 415/MR SIF54S30 420/MR SIF54S30 425/MR
Maximum power (Pmax) [W] 400 405 410 415 420 425
Open-circuit voltage (Voc) [V] 37.07 37.23 37.32 37.45 37.58 37.72
Operating voltage at the point of maximum power (Vmp) [V] 31.01 31.21 31.45 31.61 31.8 31.98
Short-circuit current (Isc) [A] 13.79 13.87 13.95 14.02 14.1 14.18
Operating current at maximum power point (lmp) [A] 12.9 12.98 13.04 13.13 13.21 13.29
Module efficiency [%] 20.5 20.7 21 21.3 21.5 21.8
Power Tolerance 0~+3%
Temperature coefficient of short-circuit current (α_Isc) +0.045%/C
Temperature coefficient of open-circuit voltage (β Voc) -0.275%/C
Maximum power temperature coefficient (γ_Pmp) -0.350%/C
Standard Test Conditions (STC) Irradiance 1000W/m2,Cell temperature 25℃,Spectral AM 1.5G
